Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins

Product Details

Place of Origin: China

Brand Name: BOX SPACE

Model Number: Detachable container

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: USD1295/unit

Packaging Details: Bubble films wrapped

Delivery Time: 7 days

Payment Terms: T/T

Supply Ability: 5000 units per month

Get Best Price
Contact Now
Specifications
Highlight:

Earthquake Resistant Portable Site Office Cabin

,

20ft Portable Site Office Cabin

,

20ft Temporary Site Cabins

Size:
5950L*3000W*2800H Mm(Can Be Customized)
Frame:
Q235B Galvanized Steel
Wall:
50/75mm Rockwool Sandwich Panel
Floor:
18mm MGO/Cement Fiber Board
Roofing:
40mm Glass Wool Insulation Layer
Anti-rust:
110um Powder Coating+Galvanized
Painting:
Powder Coating
Color:
Customized
Installaion:
4 Workers 2 Hours
Leadtime:
7 Days
Wind Resistence:
120KM/H
Anti-seismic:
Grade 8
Size:
5950L*3000W*2800H Mm(Can Be Customized)
Frame:
Q235B Galvanized Steel
Wall:
50/75mm Rockwool Sandwich Panel
Floor:
18mm MGO/Cement Fiber Board
Roofing:
40mm Glass Wool Insulation Layer
Anti-rust:
110um Powder Coating+Galvanized
Painting:
Powder Coating
Color:
Customized
Installaion:
4 Workers 2 Hours
Leadtime:
7 Days
Wind Resistence:
120KM/H
Anti-seismic:
Grade 8
Description
Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins

Temporary Prefab Container Dormitory For Construction WorkerAccommodation



DETACHABLE CONTAINER HOUSE



Detachable container is a fully demountable structure, which allows it to be loaded with far more quantity than other products, and also makes it can be customised to any size .

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 0

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 1Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 2

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 3Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 4





Installation

4 workers+2 hours = 1 unit



Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 5





Packing

Frames: Bubble films wrapped

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 6



Loading

1*40HQ can load 17 units

1*20GP can load 7 units

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 7

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 8





Specifications



Detachable container specifications
Specification Length * width * height (mm) Exterior Size:5950 × 3000 × 2800mm
Roof form Flat roof, drainage within the organization
The layer number ≤3layer
Datas Life time 15 years
Floor live load 2.0KN/
Roof live load 0.7KN/
Wind resistance 120KM/H
Anti earthquake standard Grade 8
Item Name Unit Qty Length Thickness
Frame
(all frame 110g galvanized technic)
Top beam Strip 2 5630mm 2.3mm
Strip 2 2680mm
Bottom beam Strip 2 5630mm
Strip 2 2680mm
Column Strip 4 2480mm
Corner piece pc 8 160x160x160mm 3.5mm
Slot Galvanized buckle groove Strip 2 5730mm 1.1mm
Strip 2 2800mm
Top & Bottom purlin & square tube
(galvanized technic)
Bottom purlin Strip 9 50*100*2990mm 1.2mm
Top purlin Strip 2 50*50*2800mm 1.5mm
Strip 3 40*80*1880mm 1.1mm
Strip 6 40*60*1880mm 1.0mm
Roof 980 type pressed tile pc 6 2950mm 0.5mm
Ceilling pc 6 2800mm 0.25mm
Floor MGO Board pc 5 1147*2800mm 18mm
Flooring PVC flooring roll 1   1.6mm
Wall panel both sides color steel 50mm rock wool sandwich panel
(Volumn weight: 60KG/m³)
pc 16 2560*950mm 0.326mm
Door Fire proof steel doors Set 1 950*2035 mm
Window UPVC sliding window Set 2 925*1200mm
Rub Tape Rub Tape pc 1
Roof insulation 40mm glass wool insulation layer Roll 1
Electric system Distribution box
including air opening, leakage protection
pcs 1
Wirings
220-250Voltage
4
for input
2.5
for socket/AC
1.5
for lights
Set 1
LED light, 36W pcs 2
Sockets
3 for sockets(10A)
1 for AC(16A)
pcs 4
Switch pcs 1









Projects



Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 9

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 10

Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 11Earthquake Resistant Portable Site Office Cabin , 20ft Temporary Site Cabins 12
