Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001

Product Details

Place of Origin: CHINA

Brand Name: BOX SPACE

Certification: CE ISO9001

Model Number: Flat pack container

Payment & Shipping Terms

Minimum Order Quantity: 4 unit

Price: USD1695/unit

Packaging Details: PVC films wrapped

Delivery Time: 7-14 days

Payment Terms: T/T

Supply Ability: 3000 units per month

Get Best Price
Contact Now
Specifications
Highlight:

ISO9001 2 Bedroom Container House

,

20ft Prefabricated Tiny Homes

,

2 Bedroom Container House 20ft

Size:
5800L*2400W*2896H Mm(Can Be Customized)
Frame:
Q235B Galvanized Steel
Wall:
50/75mm Rockwool Sandwich Panel
Floor:
18mm Cement Fiber Board+PVC Flooring
Roofing:
40mm Glass Wool Insulation Layer
Anti-rust:
110um Powder Coating+Galvanized
Painting:
Powder Coating
Color:
Customized
Installaion:
3 Workers 2 Hours
Leadtime:
7-14 Days
Wind Resistence:
120KM/H
Anti-seismic:
Grade 8
Size:
5800L*2400W*2896H Mm(Can Be Customized)
Frame:
Q235B Galvanized Steel
Wall:
50/75mm Rockwool Sandwich Panel
Floor:
18mm Cement Fiber Board+PVC Flooring
Roofing:
40mm Glass Wool Insulation Layer
Anti-rust:
110um Powder Coating+Galvanized
Painting:
Powder Coating
Color:
Customized
Installaion:
3 Workers 2 Hours
Leadtime:
7-14 Days
Wind Resistence:
120KM/H
Anti-seismic:
Grade 8
Description
Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001

Project Solution Modular Prefabricated Container House Quickly Assemble Low Cost Tiny Movable Houses

FLAT PACK CONTAINER HOUSE



Product Description:

BOX SPACE Flat pack container is a modular house with the top and bottom prefabricated in factory, which will help you save a lot of time and labour on installation. At the same time, its efficient internal drainage system, and stronger frame, gives it greater safety and durability.

It features a flat roof, insulation sandwich panel walls, a steel door and two windows,and it's customizable in size and color. Installation is easy and fast, making it the perfect choice for worker dormitory, hotel, site office, school, personal apartment, and even for rental business.



Features:

  • Loading: 1*40HQ can load 6~8 units(Depends on wall thickness)
  • Prefabriciated top and bottom
  • Four hiden pipes for efficient drainage
  • "Sandwich" packing for easy distinguish
  • Strong wind and earthquake resistance



Structure:

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 0

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 1

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 2





Specifications:

Flat pack container specifications
Specification Length * width * height (mm) Exterior Size:5800L ×2400W× 2896H mm
Roof form Flat roof, drainage within the organization
The layer number ≤3layer
DATAS Life time 20years
Floor live load 2.0KN/㎡
Roof live load 1.0KN/㎡
Wind load 120KM/H
Anti earthquake standard Grade 8
Item Name Specification Qty Unit
Top frame system Top frame main beam 2.5mm thick, Q235B galvanized steel, 110g/m2 galvanized 4 pc
Top frame secondary beam A C type steel, 80×40mm, 1.5mm; Q235B galvanized steel, 110g/m2 galvanized 5 pc
Corner pieces shape 210x160x200mm, galvanized 110g/m2 4 pc
Skin board 0.45mm thinck 1 set
Ceilling panel V-831 moulded steel plate 0.326mm thick 6 pc
Colume system Column 210x160mm, Q235B galvanized steel, 110g/m2 galvanized 4 pc
Column stiffener L type, 2.5mm thick, 180×120×40mm shape 4 pc
Rain water pipe d=50mm, UPVC, L=2610mm 4 pc
Hexagon bolts M12×40 Hexagon bolts 48 set
Bottom system Bottom frame main beam 2.5mm thick, Q235B galvanized steel, 110g/m2 galvanized 4 pc
bottom frame secondary beam C section steel of 120*60mm, 1.5mm; Q235B galvanized steel, 110g/m2 galvanized 9 pc
corner pieces 210*150*160mm, galvanized 110g/m2 4 pc
flume t=1mm; galvanized 4 pc
Cement board 18mm Cement fiber board 6 pc
PVC carpet 1.6mmPVC flooring 14 square meters
  Column cover Column cover, 0.5mm color steel plate 4 pc
Eletrict system Distribution box including air opening, leakage protection 1 set
Industrial outlet (including plug) 16A, including cable charge 1 set
Wires 220V wirings, 6㎡ input, 4㎡ for AC, 2.5㎡ for socket, 1.5㎡ for lights 1 set
Light LED lights 4 set
Wall panel 0.326mm steel skins, 75mm rock wool sandwich panel, 80kg/m³ volume-weight 41 square meters
Door size: 840*2035mm
Steel door
1 set
Windows size: 800*1130mm
UPVC windows,4mm double glass
2 set











Installation

3 workers+2 hours = 1 unit



Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 3





Packing & Loading

"Sandwich" packing:

All walls, columns, windows, door, and other accessories are packed in one unit.



Loading: 1*40HQ can load 6-8 units (Depends on the wall thickness)

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 4





Project cases



Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 5

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 6

Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 7Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 8



Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 9Modular 2 Bedroom Container House 20ft Prefabricated Tiny Homes ISO9001 10



Support and Services:

BOX SPACE will offer a range of technical support and service options to ensure that your product is running at its peak performance. Our technical team experts are available to provide advice and assistance with any technical issues you may experience. And our customer service team is also available to answer any questions or concerns you may have regarding your purchase.
